SIOEN T1117T TYPE I TENSILE ARCHITECTURE PVC

300cm Roll Width

100m Roll Length

725 GSM

20 Warranty

View on trade portal

Request a sample

Open a Trade Account

SIOEN T1117T Type I membrane for tensile architecture.

Surface treatment FLUO2 MAXTM Titanium Dioxide (TiO2) and PVDF surface treatment for long lasting performance.

SIOEN T1117T is directly weldable PVDF for easy and efficient confectioning.
Low Wick, Flame retardant, Anti-bacterial and UV treatment for excellent weathering
resistance.

20 year warranty

Available in: White 9922

Roll Width: 300cm
Roll Length: 100 metres
Nominal Weight: 725gsm
Base Fabric: Polyester 1100 Decitex
Coating: Top Surface: PVC FLUO2 MAXTM PVDF and Titanium Dioxide (TiO2)
Bottom Surface: PVC FLUO2 MAXTM PVDF
Fire Retardant: AS/NZS 1530.2 / M2 B1 / California T19 / Gost / NFPA 701 / B-s2,Do / BS7837
Tensile Strength: Warp/Weft 3000 / 3000 N/5cm
Tear Strength: Warp/Weft 300N / 300N
Adhesion: 100N/5cm
Visible Light Transmission (Tv): 7.2%
Solar Transmission (Ts): 8.5%
Solar Reflection (Rs): 81%
Solar Reflectance Index (SRI): 102
UV Transmission (Tuv): 0%
Solar Factor (G value): 12%
Fungal Resistance: Degree 0, excellent
U/V Warranty: 20 Years
Temperature Range: -30 / +70°C
Fabrication Methods: Hot Wedge, Hot Air & High Frequency Welding, Sewing

These instructions will maintain the appearance and extend the functional life of the fabric
• PVC Coated Fabrics
• Polypropylene Woven Coated Fabrics
• PVC Coated Nylon/Polyester Fabrics

PVC Coated Nylon/Polyester Fabrics
Care instructions relate to PVC coated side only of fabrics with PVC one.

PROHIBITIONS/WARNINGS
• Do not use solvents, abrasives or harsh detergents to clean
• Do not dry clean
• Do not iron

GENERAL CARE INSTRUCTION
A regular wipe over with warm soapy water followed by rinsing with
cold water will remove normal soiling. Where a build-up has occurred,
the surface should be cleaned with a soft brush and mild, non abrasive
detergent, then rinsed thoroughly.

SPOT CLEANING/SPECIAL TREATMENTS
Mildew may be removed by wiping with a cold solution of household
chlorine bleach having 4% chlorine, in the proportion of one part in
four to water. Rinse thoroughly with cold water.
